Precision Slotting Head Attachment - SHA-125
125mm Stroke
M225
1 of 2
Hinge
2 of 2
Order Code: M225
415V / (NO PLUG)
1 Year Warranty
1 Year Warranty
Made in Taiwan
Description
Precision Slotting Head Attachment - SHA-125
125mm Stroke
Overview
Designed for turret milling machines with a tail lug.
Features
- Manufactured from heavy duty casting for rigidity
- Transmission of power is provided through a specifically designed high output worm drive
- The sliding surfaces of the Ram are hardened and ground
- One shot lubrication built in
- Emergency stop for safe operation
- Includes adjustable mounting bracket to suit most turret type milling machines
- Suits 25mm diameter tooling
Compare Product Range
Specifications
| ORDER CODE | M225 |
|---|---|
| MODEL | SHA-125 |
| (mm)Stroke | 125 |
| Ram Stroke (stroke/min.) | 30, 47, 69, 98, 140 |
| (hp)Motor Power | 3/4 |
| (V)Voltage | 415 |
| (kg)Nett Weight | 180 |
No products to compare. This is the only product in this category. Looking for it's specifications?
