Plasma Cutter AdvanceCut60

Description Specifications Compare Accessories Related Downloads

Description

Plasma Cutter - AdvanceCut60

20mm Carbon Steel

Overview

The Strata AdvanceCut60 is a powerful 60A single-phase inverter plasma cutter designed for professional fabrication and workshop cutting. Running on standard 230V 15A power, it delivers up to 20mm production cut capacity on carbon steel with smooth, clean performance. Featuring Active PFC technology, pilot arc control, CNC interface compatibility and generator-friendly operation, it is built for reliable industrial cutting in demanding environments.

Features

Strata AdvanceCut60 60A 230V Industrial Plasma Cutter
Engineered for serious workshop performance, the Strata AdvanceCut60 delivers professional-grade plasma cutting power in a compact and generator-friendly design. Whether you are cutting structural steel, fabricating components, or integrating into a CNC system, this 60A inverter plasma cutter offers precision, durability and intelligent protection.

Powerful 60A Output with 20mm Production Cut With adjustable plasma current from 20–60A, the AdvanceCut60 provides:
20mm production cut on carbon steel
25mm severance cut capacity
15mm production cut on aluminium
This makes it ideal for fabrication workshops, maintenance departments and light industrial applications.

230V Single Phase – Standard 15A Plug
Designed to operate from a standard 230V 15A power supply, the AdvanceCut60 eliminates the need for three-phase power. It is workshop-ready and suitable for job-site environments where power access may be limited.

Active PFC & Generator Friendly Design
Featuring Active Power Factor Correction (PFC), the machine improves energy efficiency and increases duty cycle performance.
It is generator compatible with a recommended 9.5kVA continuous output, making it ideal for on-site and remote applications.

Intelligent Pilot Arc System
The automatic pilot arc system allows for easy cutting on:

Painted surfaces Rusted materials Mesh and perforated steel Perforated Cut Mode improves performance on discontinuous materials and increases cutting efficiency.

CNC Interface Ready
The AdvanceCut60 includes a CNC interface connection with built-in voltage divider options, allowing seamless integration into CNC cutting tables. Ideal for fabrication shops looking to automate plasma cutting processes.

Industrial Protection & Reliability
Built for harsh workshop environments, this plasma cutter features:

IP23 industrial casing Intelligent machine protection system Temperature, voltage and current sensors Non-HF arc start for improved reliability Smart cooling fan system
Each unit is production stress-tested at 440V for rugged durability.

Air Requirements
185 l/min at 6 bar 1/4" Male Aro Type inlet
Clean, dry air is essential for optimal plasma performance.

Specifications

Compare Product Range

Specifications

ORDER CODE	W1131
MODEL	AdvanceCut60
(mm)Cutting Capacity - Steel	20
(V / amp)Voltage / Amperage	230 / 15
(amp)Recommended Plug	15
Duty Cycle	60A@20% 49A@60% 38A@100%
(amp)Current Range	20-60
(L/min /Bar)Air Flow Capacity Required	185 / 6
(kVA)Recommended Generator KVA	9.5
(mm)Dimensions	610 x 220 x 420
(kg)Nett Weight	14
